Gecen MS-2801 2x8 Multiswitch 2 in 8 out Convert DVB-S-S2 Diseqc Switch Frequency Range 950-2150MHz Satellite Signal to TV Accept more TV Program

Description:

1.2*8 ,Zinc alloy crust

2. High isolation

3. Low insertion loss

4. Switch voltage: 18V

5.Power suppied from Receiver

Specification:

1) LNB frequency range: 950 to 2,150Mhz

2) Insertion loss: 5dB

3) Return loss: 10dB

4) Isolation: 26dB

5) LNB V voltage: 13V/14V

6) LNB H voltage: 17V/18V

7) DC current consumption: 30mA

8) Max. DC current to LNB: 500mA

9) Input and output: 75Ω, F type connector

Package Includes:

1 Piece 2x8 Way
