Norsat-8115 C Band single polarization frequency reducer LNB
The Canadian Noset C-band and KU band high-frequency heads, the DRO-8115 high-frequency head model, are professional high-frequency heads for broadcasting and television. They have been used for a long time in various TV stations and monitoring stations in China, and their stability is at the leading level in China, fully satisfying the needs of signal reception.
We can order DRO-8515/DRO-8215/DRO-8115 series high-frequency heads for you
DRO-8115 C Band LNB frequency stability ± 100 KHz noise coefficient/temperature 15 ° K input frequency: 3.4GHz -4.2GHz
Noise Temperature | 15 K |
L.O. Stability | ±100 kHz |
Phase Noise | -65 dBc/Hz at 1 kHz |
| -80 dBc/Hz at 10 kHz |
| -95 dBc/Hz at 100 kHz |
Input VSWR | 2.0: 1 |
Output VSWR | 2.2: 1 |
Input Frequency | 3.40 to 4.20 GHz |
L.O. Frequency | 5.15 GHz |
Output Frequency | 950 to 1750 MHz |
Conversion Gain | 64 dB |
Output P1dB | 8 dBm |
Power Requirement | +15 t0 +24 V supplied through center conductor of IF cable |
Current drain | 130 mA |
Input Waveguide | CPR 229G |
Dimensions | 180 (L) x 100 (W) x 70 (H) mm |
| 7.1 x 4.0 x 2.8 in |
Weight | 425g/15 oz |
Temperature Range | -40°C to +60° |
