GARDINER GKF-8488KU Universal quattro lnb
Featuring high sensitivity, high gain, low noise coefficient, and low phase noise, it is fully suitable for satellite digital TV reception requirements;
GKF8488 biased dual local oscillator high-frequency head, suitable for Ku biased antenna;
GKF-8488 adopts high-quality plastic shell with electrostatic spraying, which is elegant and beautiful;
It has been fully tested and certified by national professional organizations, and has been widely used in CATV front-end systems and household satellite receiving stations.
Jiadun GKF-8488KU Band Bipolar Single Output Feed Integrated Satellite High Frequency Head Welcome Phone Consultation
技术指标：
频率规模 12.25~12.75GHz
输出频率 950~1450MHz
增益 60Db (type)
增益平坦度 ±0.5dB/27MHz
本振频率11.3GHz
本振安稳度 ±500KHz
本振相位噪声 -60dBc/Hz (@1KHz)；-80dBc/ Hz(@10KHz)；-100dBc/Hz (@100KHz)
噪声系数 0.6dB
穿插隔离度 27Db (min.)
寄生输出 -60dBc (max.)
输出端电压驻波比 2.0:1 (max.)
1dB增益紧缩点输出功率 0.0dBm (min.)
镜像抑制 50dB
极化方法挑选 11.5V~14.2V笔直极化；15.8V~19.0V水平极化（零刻度与地上笔直时）
电源供电 10~24V PC，180mA (max.)
工作温度 -30~60℃
本公司所销售的GARDINER品牌系列：KU波段，GKF-4100,GKF-8100,GKF-6100，GKF-8488 等类型 详细请来电洽询，均保修一年，雷击与人为损坏在外！
